Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 92

10.2.1 SLVS Design Guidelines

Table 10-12 shows the SLVS interface signal routing requirements.

Table 10-12. SLVS Interface Signal Routing Requirements

Parameter Requirement Units Notes

Max Data Rate 2.4 Gbps

Max Insertion Loss (SDD21)

0GHz

1.25GHz

2.5GHz

5.0GHz

-0.88

-2.8

-4.1

-6.6

Max Return Loss (SDD11)

0GHz

1.25GHz

2.5GHz

5.0GHz

-25

-18

-15

-10

Max Crosstalk (PSFEXT)

0GHz

1.25GHz

2.5GHz

5.0GHz

-50

-45

Reference plane GND

Trace Impedance – Diff pair / Single Ended 85 Ω ±15%

Trace spacing

Between Differential Pairs

To other signal traces

dielectric

Max Intra-pair Skew 4 ps See Note

Noise Coupling Avoidance

Keep critical traces away from other signal traces or

unrelated power traces/areas or power supply components

Note: If routing to device includes a flex or 2nd PCB, the skew calculations must include all the PCBs/flex routing
