Chapter 17. Unused Interface
Terminations
17.1 Unused MPIO Interfaces
The following Jetson AGX Xavier pins (and groups of pins) are Jetson AGX Xavier MPIO (Multi-
purpose Standard CMOS Pad) pins that support either special function IOs (SFIO) and/or GPIO
capabilities. Any unused pins or portions of pin groups listed in the following table that are not
used can be left unconnected.
Table 17-1. Unused MPIO Pins and Pin Groups
Module Pins / Pin Groups Module Pins / Pin Groups Module Pins / Pin Groups
I2Sx, AUD_MCLK, DSPKx, DMICx SLVSx GPIO_AO_RET
SDMMCx IQCx WDT_RESET_x
MIPI_TRC_x UFSx TOUCH_x
EQOSx PEx, PEX_CLKx EXTPERIPHx
QSPIx DP_AUXx IGPUx
Ux3_x GP_PWMx SATA_LED_ACTIVE
I2Cx CCLAx NV_THERMx
SPIx SCE_SAFE_STATE ISTCTRLx
CANx SOC_THERMx DCx
VGPx PMICINTR DGPU_x
17.2 Unused SFIO Interface Pins
See the “Unused SFIO (Special Function I/O) Interface Pins” section in the pin description
checklist attached to this design guide.
To access the attached file, click the Attachment icon on the left-hand toolbar on this PDF
(using Adobe Acrobat Reader or Adobe Acrobat). Select the file and use the Tool Bar options
(Open, Save) to retrieve the documents.
Excel files with the .nvxlsx extension will need to be renamed to .xlsx to open.
