Main Connector Details

Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 9

3.1 Connector Pin Orientations

The symbol pinout for the 699-pin connector on the carrier board is mirrored such that the pin

numbers match when the module and carrier board connectors are mated. See the following

figure. The orientation shown matches the carrier board in the upright position as well as the

layout file.

Figure 3-2. 699-pin Connector Pin Orientations

Pin A63

(GND)

Pin L63

(PRSNT1)

Pin L63

(PRSNT1)

Pin A63

(GND)

Pin A3

(PRSNT0)

Pin L3

(GND)

Pin A3

(PRSNT0)

Pin L3

(GND)
