Table 10-5. CSI Configurations C-PHY – x3 and x1

Camera #

SoC Balls

Blocks

C-

PHY

Lanes

#1 #2 #3 #4 #5 #6

CSI_0_CLK_P,

CSI_0_D0_P/N

0:0

√

CSI_0_CLK_N,

CSI_0_D1_P/N

0:1 √

CSI_1_CLK_P.

CSI_1_D0_P/N

1:0 √

CSI_1_CLK_N,

CSI_1_D1_P/N

1:1 √

CSI_2_CLK_P,

CSI_2_D0_P/N

2:0 √

CSI_2_CLK_N,

CSI_2_D1_P/N

2:1 √

CSI_3_CLK_P,

CSI_3_D0_P/N

3:0 √

CSI_3_CLK_N,

CSI_3_D1_P/N

3:1 √

CSI_4_CLK_P,

CSI_4_D0_P/N

4:0

√

CSI_4_CLK_N,

CSI_4_D1_P/N

4:1 √

CSI_5_CLK_P,

CSI_5_D0_P/N

5:0 √

CSI_5_CLK_N,

CSI_5_D1_P/N

5:1

CSI_6_CLK_P,

CSI_6_D0_P/N

6:0 √

CSI_6_CLK_N,

CSI_6_D1_P/N

6:1 √

CSI_7_CLK_P,

CSI_7_D0_P/N

7:0 √

CSI_7_CLK_N,

CSI_7_D1_P/N

7:1

Notes: Each of the above blocks (x4) can be swapped for one of the 2x2 or 1x4 configurations.
