Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 3

Chapter 2. Jetson AGX Xavier

Jetson AGX Xavier resides at the center of the embedded system solution and includes:

 Power (PMIC/Regulators, etc.)

 DRAM (LPDDR4x)

 eMMC

 Power and Voltage Monitors

 Thermal Sensor

Table 2-1. Jetson AGX Xavier Specifications

Category Function Category Function

USB USB 2.0 (x4)

USB 3.1 (Up to x3)

PCIe x5 (x1 Root Port or Endpoint

and x4 Root Port only

Camera CSI (6x2 or 4x4) D-PHY and C-

PHY

Display HDMI / DP (up to x3) see note

HPD x3, CEC x1, DP_AUX/DDC

LAN Gigabit Ethernet RGMII I/F SPI x3

SD Card SD card or SDIO Fan PWM and TACH

Audio I2S (x4), control and clock

Digital Mic and Speaker IFs

Debug JTAG and UART

CAN x2 System Power control, Reset, Alerts

I2C x8 Power Main Inputs (HV and MV)

UART x5

Note: HDMI and DP share the same pins. See Chapter 9 for display details.
