Miscellaneous Interfaces

Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 104

Table 13-2. I2C Interface Mapping

Controller

Module Pin

Names (Xavier

Pins)

Usage on Module

Xavier

Block

On-Module Pull-

up/Voltage

I2C1 I2C1_CLK/DAT ID EEPROM (7h50) CONN 1KΩ to 1.8V

I2C2 I2C2_CLK/DAT Current Monitors (7H40 and 7H41) AO 1KΩ to 1.8V

I2C3 I2C3_CLK/DAT CAM 1KΩ to 1.8V

I2C4 DP1_AUX_CH_N/P EDP 1KΩ to 1.8V

I2C5 (PWR_I2C_SCL/SDA)

On-module only

System control. On JAXi only, routed to mux

with VM_I2C. Output of mux controls to voltage

monitors. VM_I2C controls monitors when

Xavier reset is low. PWR_I2C when reset is

high.

SYS 1KΩ to 1.8V

I2C6 DP0_AUX_CH_N/P EDP None

I2C7 DP2_AUX_CH_N/P EDP None

I2C8 I2C4_CLK/DAT AO 1KΩ to 1.8V

I2C9 I2C5_CLK/DAT EDP 1KΩ to 1.8V

na VM_I2C_SCK_DAT See I2C5 row Usage on Module description. na None
