Nvidia Jetson AGX Xavier Series User Manual

Jetson AGX Xavier
Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 7
G H J K L
22 UPHY_TX1_N GND UPHY_TX0_P GND SYS_VIN_MV
23 UPHY_TX1_P GND UPHY_TX0_N GND SYS_VIN_MV
24 GND NVHS0_TX0_P GND NVHS0_TX1_N GND
25 GND NVHS0_TX0_N GND NVHS0_TX1_P GND
26 NVHS0_TX2_N GND NVHS0_TX3_P GND SYS_VIN_MV
27 NVHS0_TX2_P GND NVHS0_TX3_N GND SYS_VIN_MV
28 GND NVHS0_TX4_P GND NVHS0_TX5_N GND
29 GND NVHS0_TX4_N GND NVHS0_TX5_P GND
30 NVHS0_TX6_N GND NVHS0_TX7_P GND SYS_VIN_MV
31 NVHS0_TX6_P GND NVHS0_TX7_N GND SYS_VIN_MV
32 GND RSVD GND RSVD GND
33 GND RSVD GND RSVD GND
34 RSVD GND RSVD GND SYS_VIN_MV
35 RSVD GND RSVD GND SYS_VIN_MV
36 GND RSVD GND RSVD GND
37 GND RSVD GND RSVD GND
38 RSVD GND RSVD GND SYS_VIN_MV
39 RSVD GND RSVD GND SYS_VIN_MV
40 GND MID1 GND MID0 GND
41 CSI1_D0_P GND CSI1_D1_P GND RSVD
42 CSI1_D0_N CSI1_CLK_N CSI1_D1_N GND RSVD
43 GND CSI1_CLK_P GND CSI6_D0_N GND
44 CSI3_D1_P GND CSI6_CLK_P CSI6_D0_P VM_I2C_SCK
45 CSI3_D1_N CSI6_D1_N CSI6_CLK_N GND VM_I2C_DAT
46 GND CSI6_D1_P GND HDMI_DP0_TX3_P GND
47 CSI4_D0_N GND HDMI_DP0_TX2_P HDMI_DP0_TX3_N VM_INT_N
48 CSI4_D0_P HDMI_DP0_TX0_N HDMI_DP0_TX2_N GND UART4_RX (RSVD)
49 GND HDMI_DP0_TX0_P GND GPIO25 UART4_CTS
50 HDMI_DP0_TX1_N GND HDMI_CEC DP2_HPD GPIO35
51 HDMI_DP0_TX1_P GPIO26 GPIO24 DP1_HPD UART1_RTS
52 GND GPIO27 DP1_AUX_CH_P DP0_HPD OVERTEMP_N
53 DP2_AUX_CH_P MCLK03 DP1_AUX_CH_N UART1_TX VCC_RTC
54 DP2_AUX_CH_N UART1_CTS MCLK02 UART1_RX MODULE_POWER_
ON
55 GPIO23 MCLK04 GPIO32 GND VDDIN_PWR_
BAD_N
56
SPI3_MOSI
GND
GND
GPIO19
TEMP_ALERT_N
57 GND UART5_CTS SPI1_CLK PWM01 MCLK05
58 UART2_RTS UART5_RX UART5_TX UART5_RTS PERIPHERAL_
RESET_N
59 TEMP_ALERT_OUT
(JAXi only)
NVJTAG_SEL I2S3_DIN I2S3_DOUT RSVD
60 NVDBG_SEL GPIO31 STANDBY_ACK_N UART3_RX_DEBUG SYS_RESET_N
61 JTAG_TRST_N CAN1_DOUT I2C2_CLK I2C2_DAT POWER_BTN_N
62 GND UART3_TX_DEBUG GND FAN_PWM CARRIER_POWER_
ON
63 SYS_VIN_HV GND SYS_VIN_HV GND PRSNT1
64 SYS_VIN_HV SYS_VIN_HV SYS_VIN_HV
65 SYS_VIN_HV SYS_VIN_HV SYS_VIN_HV
Legend
Ground Power
Reserved – Must be left unconnected
unless otherwise directed.
No pins at that
location
JAXi only
Safety MCU
usage on JAXi
