Panasonic NN-CS596S User Manual

20
Control Panel
(1) Display Window
(2) Microwave Power Pad
(3) Steam Power Pad
(4) Grill Pad
(5) Convection Pad
(6) Timer Pad
This can be used to delay a cooking
program for up to 9 hrs 99 mins., or
used as a timer or for standing
(non-cooking) time. Also used for
setting the clock.
(7) Auto Weight Programs
(8) Auto Menu/ Temperature/
Microwave/Steam wattage/ Grill
level/ Selector dial
(9) Time/Weight dial
(10) Stop/Cancel
Before Cooking:
one press clears your instructions.
During Cooking:
one press temporarily stops the
cooking program. Another press
cancels all your instructions and the
time of day will appear in the display.
(11) Start Pad:
Press to start operating the oven.
If during cooking the door is opened or
Stop/Cancel Pad is pressed once,
Start Pad has to be pressed again to
continue cooking.
(12) Water tank for steam function
(1)
(2)
(3)
(4)
Beep Sound:
A beep sounds when a pad is pressed. If this
beep does not sound, the setting is incorrect.
When the oven changes from one function to
another, two beeps sound. After completion of
preheating on CONVECTION or
COMBINATION, three beeps sound and ‘P’
flashes in the display window. After completion
of cooking, five beeps sound.
(5)
(6)
(7)
(8)
(11)
(12)
(10)
(9)

Panasonic NN-CS596S Specifications

Power

rated voltage	230-240 V, 50 Hz
operating frequency	2, 450 MHz
input power	Max 2800 W
microwave power	1100 W
grill power	1400 W
convection power	1450 W
microwave & steam power	2050 W
output power microwave	1000 W (IEC-60705)
output power grill	1300 W
output power convection	1400 W
output power steam	1000 W

Operating Environment

noise	56 dB

Weight and Dimensions

outer dimensions width	523 mm
outer dimensions depth	494 mm
outer dimensions height	320 mm
oven cavity dimensions width	354 mm
oven cavity dimensions depth	343 mm
oven cavity dimensions height	205 mm
weight with internal accessories	18.5 kg
