YH4
GRAND
VITARA
REAR SUSPENSION 3E-23
TIGHTENING TORQUE SPECIFICATIONS
p
Tightening torque
N
.
m Kg-m lb-ft
Shock absorber lock nut 29 2.9 21.0
Shock absorber nut 29 2.9 21.0
Shock absorber lower nut 85 8.5 61.5
Lower rod bolt and nut
Upper rod bolt and nut
90 9.0 65.0
Lateral rod bolt
Differential carrier nut 55 5.5 40.0
Propeller shaft nut 50 5.0 36.5
Brake pipe flare nut 16 1.6 11.5
Bearing retainer nut 23 2.3 17.0
Differentiation
ear oil
Filler plug 50 5.0 36.5
filler & drain plug
Drain plug 27 2.7 16.0
Wheel nut 100 10.0 72.5
REQUIRED SERVICE MATERIALS
MATERIALS
RECOMMENDED
SUZUKI PRODUCT
USE
Lithium grease
SUZUKI SUPER GREASE A
(99000-25010)
Oil seal lip
Brake fluid DOT 3 Brake reservoir tank
Sealant
SUZUKI BOND NO. 1215
(99000-31110)
Joint seam of axle and brake back
plate
Joint seam of bearing retainer and
brake back plate
Joint seam of differential carrier and
axle housing
Drain plug
Mating surface of oil seal and axle
housing
Gear oil
For gear oil information, refer to
SECTION 7F of this manual
Differential gear
(Refer axle housing.)
