YH4
GRAND
VITARA
10B
AIR BAG SYSTEM 10B-1
GENERAL DESCRIPTION 10B- 3. . . . . . . . . . . . .
System Components and Wiring
Location View and Connectors 10B- 4. . . . . . .
System Wiring Diagram 10B- 5. . . . . . . . . . . . . .
DIAGNOSIS 10B- 6. . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Trouble Codes 10B- 6. . . . . . . . . . . .
Use of Special Tools 10B- 6. . . . . . . . . . . . . . . . .
Intermittent and Poor Connections 10B- 8. . . . .
Air Bag Diagnostic System Check 10B-10. . . . .
Air bag diagnostic system check
flow table 10B-11. . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic trouble code (DTC) check 10B-12.
Diagnostic trouble code (DTC)
clearance 10B-13. . . . . . . . . . . . . . . . . . . . . . .
Diagnostic trouble code table 10B-14. . . . . . . .
Table A - “AIR BAG” warning lamp
comes “ON” steady 10B-16. . . . . . . . . . . . . . .
Table B - “AIR BAG” warning lamp
does not come “ON” 10B-18. . . . . . . . . . . . . .
Table C - “AIR BAG” warning lamp
flashes 10B-20. . . . . . . . . . . . . . . . . . . . . . . . . .
Table D - SDM cannot communicate
through the serial data circuit 10B-22. . . . . . .
Code 15 - Passenger air bag initiator
circuit resistance high 10B-24. . . . . . . . . . . . .
Code 16 - Passenger air bag initiator
circuit resistance low 10B-26. . . . . . . . . . . . . .
Code 18 - Passenger air bag initiator
circuit short to ground 10B-28. . . . . . . . . . . . .
Code 19 - Passenger air bag initiator
circuit short to power circuit 10B-30. . . . . . . .
Code 21 - Driver air bag initiator
circuit resistance high 10B-32. . . . . . . . . . . . .
Code 22 - Driver air bag initiator
circuit resistance low 10B-34. . . . . . . . . . . . . .
Code 24 - Driver air bag initiator
circuit short to ground 10B-36. . . . . . . . . . . . .
Code 25 - Driver air bag initiator
circuit short to power circuit 10B-38. . . . . . . .
Code 31 - Power source voltage high 10B-40
Code 32 - Power source voltage low 10B-42.
Code 41 - Driver pretensioner initiator
circuit resistance high 10B-44. . . . . . . . . . . . .
Code 45 - Passenger pretensioner
initiator circuit resistance high 10B-44. . . . . .
Code 42 - Driver pretensioner initiator
circuit resistance low 10B-46. . . . . . . . . . . . . .
SECTION 10B
AIR BAG SYSTEM
WARNING:
Service on or around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Please observe all WARNINGS and “Service Precautions” under “On-Vehicle
Service” in this section before performing service on or around the air bag system components or
wiring. Failure to follow WARNINGS could result in unintended activation of the system or could ren-
der the system inoperative. Either of these two conditions may result in severe injury.
The procedures in this section must be followed in the order listed to disable the air bag system tem-
porarily and prevent false diagnostic trouble codes from setting. Failure to follow procedures could
result in possible activation of the air bag system, personal injury or otherwise unneeded air bag sys-
tem repairs.
CAUTION:
When fasteners are removed, always reinstall them at the same location from which they were re-
moved. If a fastener needs to be replaced, use the correct part number fastener for that application. If
the correct part number fastener is not available, a fastener of equal size and strength (or stronger) may
be used. Fasteners that are not reused, and those requiring thread-locking compound, will be called
out. The correct torque value must be used when installing fasteners that require it. If the above condi-
tions are not followed, parts or system damage could result.
