YH4
GRAND
VITARA
9
BODY SERVICE 9-1
GLASS, WINDOWS AND MIRRORS 9- 2. . . . .
Front Door Glass 9- 2. . . . . . . . . . . . . . . . . . . . .
Front Door Window Regulator 9- 5. . . . . . . . . .
Windshield 9- 6. . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Glass 9-12. . . . . . . . . . . . . . . . . . . . .
Rear Door Window Regulator 9-14. . . . . . . . . .
Quarter Window 9-15. . . . . . . . . . . . . . . . . . . . . .
Back Door Glass 9-16. . . . . . . . . . . . . . . . . . . . .
BODY STRUCTURE 9-17. . . . . . . . . . . . . . . . . . .
Front Door Assembly 9-17. . . . . . . . . . . . . . . . .
Rear Door Assembly 9-18. . . . . . . . . . . . . . . . . .
Back Door/Rear Gate Assembly 9-19. . . . . . . .
Hood 9-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Fender 9-22. . . . . . . . . . . . . . . . . . . . . . . . .
Front Bumper 9-23. . . . . . . . . . . . . . . . . . . . . . . .
Rear Bumper 9-24. . . . . . . . . . . . . . . . . . . . . . . .
Under Body Dimensions 9-25. . . . . . . . . . . . . . .
Body Dimensions 9-26. . . . . . . . . . . . . . . . . . . . .
INSTRUMENTATION AND DRIVER
INFORMATION 9-33. . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 9-33. . . . . . . . . . . . . . . . . . . . .
SEAT 9-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Seat 9-34. . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Seat 9-35. . . . . . . . . . . . . . . . . . . . . . . . . . .
PAINT AND COATINGS 9-36. . . . . . . . . . . . . . . .
Anti-Corrosion Treatment 9-36. . . . . . . . . . . . . .
Metal Replacement Parts Finishing 9-37. . . . .
Plastic Parts Finishing 9-58. . . . . . . . . . . . . . . . .
SECURITY AND LOCKS 9-59. . . . . . . . . . . . . . . .
Front Door Lock Assembly 9-59. . . . . . . . . . . . .
Rear Door Lock Assembly 9-61. . . . . . . . . . . . .
Back Door/Rear Gate Lock Assembly 9-62. . .
Key Coding 9-63. . . . . . . . . . . . . . . . . . . . . . . . . .
SUNROOF/CONVERTIBLE TOP 9-64. . . . . . . . .
Sliding Roof (if equipped) 9-64. . . . . . . . . . . . . .
Canvas Top And Topbow Frames 9-71. . . . . . .
EXTERIOR AND INTERIOR TRIM 9-72. . . . . . .
Floor Carpet 9-72. . . . . . . . . . . . . . . . . . . . . . . . .
Head lining 9-73. . . . . . . . . . . . . . . . . . . . . . . . . .
Roof Trim (2 Door Model) 9-75. . . . . . . . . . . . . .
Side Moldings (if equipped) 9-77. . . . . . . . . . . .
Splash Guard (if equipped) 9-78. . . . . . . . . . . .
Roof Rail (if equipped) 9-79. . . . . . . . . . . . . . . .
Roof Molding 9-79. . . . . . . . . . . . . . . . . . . . . . . .
Luggage Under Box 9-80. . . . . . . . . . . . . . . . . .
SECTION 9
BODY SERVICE
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System
Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
When body servicing, if shock may be applied to air bag system component parts, remove those parts
beforehand. (Refer to Section 10B.)
NOTE:
Fasteners are important attaching parts in that they could affect the performance of vital components and
systems, and/or could result in major repair expense. They must be replaced with one of the same part
number of with an equivalent part if replacement becomes necessary.
Do not use a replacement part of lesser quality or substitute a design. Torque values must be used as spe-
cified during reassembly to assure proper retention of these parts.
