7B1-56 AUTOMATIC TRANSMISSION (4 A/T)
8) Stall speed should be within the following specification.
Stall speed: 2,100 – 2,400 r/min. for G16 engine
2,300 – 2,600 r/min. for J20 engine
2,300 – 2,600 r/min. for H25 engine
Check result
Possible cause
Lower than standard
level
Faulty engine output
Defective torque converter
Higher than standard
level in “D” range
Slippery O/D clutch
Slippery forward clutch
Malfunctioning O/D one-way clutch
Malfunctioning one-way clutch No. 2
Low line pressure
Higher than standard
level in “R” range
Slippery direct clutch
Slippery reverse brake
Low fluid pressure
Slippery O/D clutch
Defective O/D one-way clutch
ROAD TEST
This test is to check if upshift and downshift take place at specified
speed while actually driving vehicle on a level road.
WARNING:
Carry out test in very little traffic area to prevent an acci-
dent.
Test requires 2 persons, a driver and a tester.
1) Warm up engine.
2) With engine running at idle, shift select lever “D”.
3) Accelerate vehicle speed by depressing accelerator pedal grad-
ually.
4) While driving in “D” range, check if gear shift occurs properly as
shown in Gear Shift Diagram in this section.
Test result
Possible cause
When 1 2 upshift fails to
occur
1–2 shift valve stuck
When 2 3 upshift fails to
occur
2–3 shift valve stuck
When 3 O/D upshift
fails to occur
3–4 shift valve stuck
When gear shift point is in-
correct
Maladjusted throttle cable
Defective shift solenoid valve
-A or -B
1–2, 2–3 or 3–4 shift valve not
operating properly
To Next Page
