YH4

GRAND

VITARA

5E1-42 ANTILOCK BRAKE SYSTEM (ABS) (OPTIONAL)

09950-78220

Flare nut wrench

(10 mm)

09931-76011

SUZUKI scan tool (Tech 1A) kit

1. Storage case

2. Operator’s manual

3. Tech 1A

4. DLC cable

5. Test lead/probe

6. Power source cable

7. DLC cable adapter

8. Self-test adapter

Mass storage cartridge

09931-76030

16/14 pin DLC cable

SPECIAL TOOLS
