YH4

GRAND

VITARA

AUTOMATIC TRANSMISSION (4 A/T) 7B1-79

09925-37810

Oil pressure gauge

09927-56010

Gear stopper

(only for G16/J20)

09931-76030

16/14 pin DLC

(OBD-II adapter) cable

09931-76011

SUZUKI scan tool (Tech 1A) kit

1. Storage case

2. Operator’s manual

3. Tech 1A

4. DLC cable

5. Test lead/probe

6. Power source cable

7. DLC cable adapter

8. Self–test adapter

Mass storage cartridge

REQUIRED SERVICE MATERIALS

MATERIAL

RECOMMENDED

SUZUKI PRODUCT

USE

A/T fluid An equivalent of DEXRONr-III

D Automatic transmission

D Parts lubrication when installing

Lithium grease

SUZUKI SUPER GREASE A

(99000–25010)

D Cable ends

Sealant

SUZUKI BOND NO.1215

(99000-31110)

D Flywheel bolts

SPECIAL TOOLS
