YH4

GRAND

VITARA

9-80 BODY SERVICE

1. Bolt

2. Member

LUGGAGE UNDER BOX

WARNING:

Do not remove member in the center of luggage under box.

If member had to be removed temporarily for repair or for some oth-

er reason, be sure to reinstall it by using specified new bolts until

head of bolt is broken off.
