Section 7. Component Procedures Toyota Orderpicker Model 7BPUE 15 Service Manual
Operator Console Cover Covers and Finish
Operator ConsoleCover Installation
1. Position cover over console components
Make sure the operator platform is fully
lowered before placing any part of your
body between the masts.
Figure 7 - 1 1.
Operator Console, Cover Installed
Removal
Figure 7 - 12. Operator Console, Cover Removed
1. Lower platform to the floor. Turn key
switch off and disconnect battery.
2. Loosen the two captivating knobs located
on each side of the cover.
and secure to the platform with
- the two
captivating knobs.
00700 - CL222 - 05, 1 5 March 2005
