Section 7. Component Procedures
Toyota
Orderpicker Model 7BPUE 15 Service Manual
Lift Pump and Motor
H
y
draulic Components
Lift
Pump
and
Motor
6. Remove and replace both hydraulic fittings
on the lift pump.
Figure 7
-
92. Pump Location
Replace
1. Remove top and tractor covers.
2.
Turn key switch OFF and disconnect
battery.
N
OTE
:
In the next steps you will need a
5
gallon
(19 liter) capacity container.
3.
Drain hydraulic fluid. See
"
Hydraulic
Fluid
"
on page 7
-
60.
N
OTE
:
Make
sure hoses are disconnected from
pump.
4. Remove the two mounting bolts securing
the lift pump to the lift motor. See
Figure 7
-
93.
5.
Carefully separate the pump from the
motor, taking care not to damage the
toothed spline.
Figure 7
-
93. Pump and Motor Connection
7. Apply molybdenum anti
-
seize compound
(P/N
00590
-
04836
-
71) to the mating
surfaces of the lift motor spline and pump.
8. Carefully mate the new lift pump spline to
the lift motor and attach the lift pump to
the lift motor with the two mounting bolts.
9. Replace the filter on the manifold. See
Figure 7
-
92.
10. Connect hoses.
11. Insert drain plug in drain hose and fill the
hydraulic reservoir with new fluid.
12. Connect power and test lift functions
before returning truck to service.
13. Bleed the hydraulic system as necessary.
14. Install tractor covers.
