Section 7. Component Procedures Toyota Orderpicker Model 7BPUE 15 Service Manual
Forks
Forks
Remove
1. Raise operator platform high enough to
reach bottom of forks.
2.
Block operator platform with 4
x
4
"
(10
x
10 cm) upright block.
3.
Secure fork to hoist using a suitable strap
or chain.
4. Remove one socket head cap screw from
underneath fork at tractor end. See
Figure
7
-
142.
5.
Remove snap ring from pivot pin in
mounting block of fork.
Mast Section
Install
1. Hold new fork in place underneath
operator platform.
Figure
7
-
144. Installing Forks and Shims
2.
Install pivot pin through fork.
N
O
T
E
:
Always use new snap rings when
assembling components.
3. Install new snap ring in pivot pin. See
Figure
7
-
143.
4. Install correct amount of washers or shim
at back side of fork to maintain a level
fork. See Figure 7
-
144.
5.
Install socket head cap screw at tractor
end of fork.
Figure
7
-
143. Snap Ring, Pivot Pin and Mounting Block
6.
Remove block from operator platform.
7. Lower operator platform to floor and make
The fork will drop in step
6.
It weighs
approximately
150
Ib.
(68
kg).
6.
Drive out pivot pin. The fork, washers or
shim will drop. See Figure 7
-
143.
7. Replace damaged fork.
sure forks are level. If forks are not level,
add more shim to fork.
00700
-
CL222
-
05,
1
5
March 2005
