Toyota Orderpicker Model 7BPUE 15 Service Manual Section 7. Component Procedures
Mast Section Inner Mast
installation
5. Apply adhesive (P/N 00590 - 04964 - 7 1) to
bolts and install chain pulleys. See
1. Line up bottom roller bearings in the outer
Figure 7
- 125.
mast channel and lower into main frame.
See Figure
7 - 124.
Figure 7 - 125. Attaching C
y
linder and lnner mast
6. Install chains and secure in chain
anchors. See Figure 7
- 126.
Install upper roller bearings on the outer
mast.
Remove block from outer mast and lower
both masts.
Install bolt in the top of each piston. See
Figure
7 - 125.
00700 - CL222 - 05, 1 5 March 2005
Figure 7 - 126. lower Chain Anchor Block
7. Install center cylinder. See " Center
Cylinder
" on page 7 - 69.
8. Install over - the - mast hose and cable
pulleys to outer mast.
9. Install hoist on outer mast and lift until
inner mast raises enough to expose cable
bracket.
