Toyota Orderpicker Model
7BPUE
15 Service Manual Section
3.
Systems Overview
Installation lnstructions
Installation Instructions
N
O
T
E
:
These instructions pertain to trucks that
are shipped horizontally on a cradle.
1.
Remove long bolts from bumper plate (two
bottom bolts).
2. Remove banding, forks and truck from
cradle.
3.
Use two hoists in conjunction to stand
truck upright.
4. Install
2
bumper plate bolts.
5.
Install dipstick in drive unit.
6.
Remove shipping cap and screws in
hydraulic reservoir and install cap and
screen.
7. Install forks. See
"
Forks
"
on page 7
-
94.
8.
Install battery. See
"
Battery Procedures
"
on page 7
-
32.
9. Connect battery, turn key switch
ON
and
test truck functions.
00700
-
CL222
-
05,
1
5 March 2005
