Toyota Orderpicker Model 7BPUE 15 Service Manual Section 7. Component Procedures
Mast Section Lift Chains, Two
-
Stage
Lift
Chains, Two
-
Stage
8.
Connect power and test lift function before
returning truck to service.
Use extreme care whenever the truck
is
jacked up. Never block the truck
between the mast and the floor. Keep
hands and feet clear from vehicle while
jacking the truck. After the truck
is
jacked, place solid blocks beneath it to
support it. DO NOT rely on the jack
alone to support the truck. See
"
Jacking
Safety
"
on page
2
-
1
1.
Figure
7
-
142. Unbolting Forks
Figure
7
-
14 1. Outside Chain Anchor, Side View
1. Attach suitable hoist and block carriage
just enough to gain slack on chains.
2.
Disconnect chain anchors from both sides.
See Figure
7
-
140 and Figure
7
-
141.
3.
Replace chains as necessary.
4. Connect outside chain anchor. See
Figure
7
-
14 1.
5.
Feed chain over pulley.
6.
Connect chain to inside anchor. See
Figure
7
-
140.
7.
Remove block and hoist.
00700
-
CL222
-
05,
1
5 March 2005
