Section 7. Component Procedures Toyota Orderpicker Model 7BPUE 15 Service Manual
Circuit Cards (General) Electrical Components
Circuit Cards (General)
2.
Remove appropriate cover(s). See
"
Tractor
Covers
"
on page
7
-
1 1.
3.
If removing a circuit card from tractor,
-
remove circuit card cover.
4.
Disconnect all connectors on this circuit
card.
5.
Remove all screws holding circuit card to
frame.
Figure 7
-
80. Steer/Tractor Manager Circuit Card
Figure 7
-
82. Carriage Manager in Operator Console
Installation
1. Install new circuit card with the screws
Figure 7
-
8
1
:
Steer Power Head Circuit Cart
you removed earlier.
2.
Attach connectors to circuit card.
3.
Connect battery connector and turn key
ACAUTION
switch
ON.
Use proper precautions against
electrostatic discharge. See
"
Static
Safety
"
on page
2
-
9.
4.
If installing a circuit card in the tractor,
install circuit card cover.
5.
Install appropriate cover(s).
N
O
T
E
:
Before removing a good carriage
6. Connect power and test operation before
manager, use the
Flashware Program to
returning truck to service.
clear the memory. See
"
Clear Primary
Memory
"
on page 10
-
6.
Removal
1. Turn key switch OFF and disconnect
battery.
00700
-
CL222
-
05,
1
5
March 2005
