Toyota Orderpicker Model 7BPUE 15 Service Manual
Section
7. Component Procedures
Mast Section
Skid Pads
Skid Pads
Location
There are two skid pads on each truck.
Inspection
1. Check clearance between each skid pad
and floor.
2. If clearance is more than 3/4 inch
(19.1 mm) on either side, replace skid pad.
See procedure below.
Use extreme care whenever the truck is
jacked up. Keep hands and feet clear of
from the vehicle while jacking the truck.
After the truck
is jacked, place solid
blocks beneath it to support it.
DO NOT
rely on the jack alone to support the
truck. See
" Jacking Safety " on
page
2 - 1 1.
Replacement
Weld new skid pad inside worn skid pad.
Clearance from floor should be
3/4 inch
(19.1 mm).
00700 - CL222 - 05, 1 5 March 2005
