Section
3.
Systems Overview Toyota Orderpicker Model
7BPUE
15 Service Manual
Special Tools
Special Tools
BDI (Battery Discharge Indicator) cutout
threshold
Options
Learn throttle
Diagnostics
For operating instructions, See
"
PC Loader
Program
"
on page 10
-
2.
Ram Service Tools
Use these tools when repacking the side
cylinders or center cylinder.
Figure
3-4.
Programmable Maintenance Tool
Pro rammable Maintenance
Too
f
The optional programmable maintenance tool
(PMT) (P/N 00590
-
49981
-
71) allows you to test,
program (or configure) and diagnose the
traction power amplifier in this truck.
Lift/Lower Pendant
The PMT is powered by the host amplifier
The
lift/lower pendant (P/N 00590
-
46325
-
7 1) is
through the four
-
pin connector at the top
a tool that allows you to use the hydraulic
corner of the traction power amplifier. See
system independent of the lift and lower
Figure 3
-
4.
switches. This pendant connects to the
Tool
Side Cylinder Service Guide
Side Cylinder Service Driver
Center Cylinder Service
Guide
Center Cylinder Service
Driver
steer/tractor manager at JT1.
See
"
Programmable Maintenance Tool
"
on
page 5
-
20.
Part
Number
00590
-
454 16
-
7 1
00590
-
454 15-7 1
00590
-
05258
-
7 1
00590
-
05257
-
7 1
Pin Extractor
Use the pin extractor (P/N 00590
-
04672
-
71)
when removing wires from any connectors.
FlashWare
The FlashWare software allows you to update
truck software, configure options and
troubleshoot electrical components on this lift
truck. Selections include:
Flash memory program
Clear primary memory
00700
-
CL222
-
05,
1
5
March 2005
