Section
9.
Theory of Operation Toyota Orderpicker Model
7BPUE
15 Service Manual
Battery Plugged In
Battery Plugged
In
Refer to the schematic in Figure 9
-
2 on
page 9
-
6.
When a properly charged battery is connected
to the
truck battery positive is present with
reference to TP4
(B-) at the following points:
1.
B+ side (PC
-
1) of the open PC contactor tip
2.
JPT12-11 and JPT12-120n the
steer/tractor manager (STM)
3.
FU2 on the steer/tractor manager
4.
JPT12-24 (horn) on the steer/tractor
Manager as B+F
5.
JPT10-2 on the steer/tractor manager to
JPC9-2 on the carriage manager (CM) as
B+F
6. JPC 1 1
-
5 on the carriage manager to
S
1
-
1
as B+F
7.
JPC 10
-
1 and JPC 10
-
2 on the carriage
manager as B+F
00700
-
CL222
-
05,
1
5
March 2005
