Xerox Phaser 6180MFP Service Manual

2-94 Phaser 6180MFP Multifunction Printer Service Manual
Theory of Operation
Telephone Call Connection Mechanism
Analog Telephone Network
To make a telephone call, the calling party and called party each must have a
telephone. These telephones must be connected by a transmission route. The
transmission route includes switches located at the central offices. The route
itself comprises various components such as metallic and optical cables. The
entire transmission path between the two telephones is called an analog
telephone network.
An analog telephone network comprises of four parts: Telephone Set, Switch,
Subscriber Line, and Transmission Route.
s6180mfp-101
Analog Telephone Network Configuration
Telephone set Telephone setSwitch Switch
Subscriber line Transmission route Subscriber line
s6180mfp-102
Switching Equipment Network
Telephone Set
Telephone Set
Telephone Set
Telephone Set
Local Switch
Local Switch
Local Switch
Local Switch
Tandem Switch
Tandem Switch
Tandem Switch
