3-22 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Jam at Scanner
Jam has occurred at the ADF. The following troubleshooting procedure
applies to these errors.
Applicable Chain Link
■ Chain Link 005-110: Jam at Scanner (Pickup Jam)
■ Chain Link 005-121: Jam at Scanner (ADF Jam)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
■ ADF Scanner Assembly, PL11.1.1
■ ADF Feed Roller, PL11.1.3
■ “Map 3 - Image Processor Board and
Dispenser Motors” on page 10-12
■ “Automatic Document Feeder Wiring
Diagram” on page 10-53
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the original document.
2.Does the document meet the ADF
specifications?
Go to step 2. Use the
document glass
mode or change
the paper type.
2 1.Check the ADF.
2.Is the ADF completely closed?
Go to step 3. Close the ADF.
3 1.Check the paper feeding.
2.Did the document feed through the
ADF?
Go to step 4. Go to step 5.
4 1.Check the document path.
2.Are there debris on the document
path?
Remove the
debris.
Go to step 7.
5 1.Check the ADF Feed Roller for
correct installation and damages.
2.Is the ADF Feed Roller correctly
installed?
Go to step 6. Is the ADF Feed
Roller
damaged?
Replace the
ADF Feed Roller
(page 8-110).
