10-2 Phaser 6180MFP Multifunction Printer Service Manual
Plug/Jack and Wiring Diagrams
Plug/Jack Diagrams and Designators
This chapter contains the Plug/Jack Designators, Locators, and wiring
diagrams for the print engine and all options.
The Plug/Jack Locator diagrams show the P/J locations within the printer,
Optional 550-Sheet Feeder, Duplex Unit, Fax, Copier, and Scanner. Use
these illustrations to locate P/J connectors called out in the Troubleshooting
procedures presented in Sections 3, 4, and 5.
The Plug/Jack locators consist of the P/J Designator Tables and the P/J
Locator Diagrams.
â–  The P/J column lists the Plug/Jack numbers in numerical order.
â–  The Map column provides the map number of the specific areas (i.e.,
Electrical, Laser Unit...etc.)
â–  The Coordinates column lists the diagram coordinates for the location of
the connector.
â–  The Remarks column provides a brief description of each connection.
1. Locate the P/J connector designator in the first column of the table.
2. With this information, go to the map listed in the second column.
3. Use the coordinates to locate the connection indicated on the map with its
P/J designation number.
Print Engine Plug/Jack Designators
Print Engine Plug/Jack Designators
P/J Map Coordinates
Remarks
3 3 E-138 Connects the Image Processor Board and Multi-
Protocol Network Card.
10 4 I157 Connects the MCU Board and AIO I/F Harness.
11 4 I-157 Connects the MCU Board and AIO I/F Harness.
12 4 I-156 Connects the MCU Board and Laser Unit Harness.
14 4 I-156 Connects the MCU Board and LVPS Harness.
15 4 H-157 Connects the MCU Board and 24V Controller
Harness.
16 4 I-156 Connects the MCU Board and HVPS.
17 4 I-156 Connects the MCU Board and Fuser Harness.
18 4 H-157 Connects the MCU Board and Toner Motor Harness.
19 4 I-157 Connects the MCU Board and Toner Sensor
Harness.
21 4 H-158 Connects the MCU Board and Right Side Harness.
22 4 H-158 Connects the MCU Board and Right Side Harness.
23 4 H-159 Connects the MCU Board and Right Side Harness.
24 4 I-159 Connects the MCU Board and Overhead Paper
(OHP) Harness.
