8-88 Phaser 6180MFP Multifunction Printer Service Manual
Service Parts Disassembly
MCU Board (PL9.2.13)
o
e
If the MCU Board is exchanged, store internal data to the Image
Processor Board. Enter Service Diagnostics menu: Service Mode >
Printer Diag > Engine Diag > NVM Settings > Save NVM to ESS. Refer
to ”Saving NVM (NVRAM)” on page 6-7 for detailed procedures.
1. Open the Front Cover.
2. Remove the Fuser (page 8-12).
3. Remove the Rear Cover (page 8-18).
4. Remove the Bottom Cover (page 8-19).
5. Remove the Left Pole Inner Cover (page 8-24).
6. Remove the Left Pole Cover (page 8-25).
7. Remove the Left Cover (page 8-26).
8. Remove the Controller Shield Box Assembly (page 8-92).
9. Remove the Fax Shield Box Assembly (page 8-96).
10. Remove the Humidity/Temperature Sensor (page 8-87).
11. Disconnect all the MCU Board connectors and release the wiring
harnesses from the Clamps.
To Next Page
