3-130 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Fan Motor Error (Main Fan)
Error for the Main Fan Motor has occurred. The following troubleshooting
procedure applies to this error.
Applicable Chain Link
■ Chain Link 042-358: Fan Motor Error (IOT Fan Motor Failure)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Fan, PL9.2.10
■ MCU Board, PL9.2.13
■ LVPS, PL9.2.14
■ LVPS Harness, PL10.1.3
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “DC Power Supply” on page 10-24
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Perform the Main Fan test
(page 4-77): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Fan.
2.Does the Motor operate properly?
Replace the
MCU Board
(page 8-88).
Go to step 2.
2 1.Check the Main Fan for correct
installation. Reseat the Main Fan
(page 8-84).
2.Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 Check the LVPS Harness for
continuity.
1.Disconnect P/J501 from the LVPS.
2.Disconnect P/J14 from the MCU
Board.
3.Check continuity between P/J501
<=> P/J14.
Go to step 4. Replace the
LVPS Harness.
4 1.Replace the Main Fan (page 8-84).
2.Does the error still occur when the
printer is turned On?
Go to step 5. Complete.
