9-26 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 7.1 Frame
ID No. Name/Description Part Number
1. Wheel Star Assy 019K08450
2. Link Assy Left (Kits)
3. Link Latch Trans (Kits)
4. Lever Release (Kits)
5. -----
6. Holder Damper H (Kits)
7. Damper Oil H (Kits)
8. Spring Support
9. -----
10. -----
11. -----
12. Link Assy Right (Kits)
13. Link Right
14. Kit Foot Assy (4 pcs) 675K35450
15. Clamp WS-2W-V0
16. -----
17. Guide Tray Right 250
18. Switch Assy Size 110K12820
19. Guide Tray Assy Left 250 (with 20, 22)
20. Guide Tray Left 250
21. -----
22. Spring Tray Lock
23. Duct Side Left
24. Stopper Frame Left
98. Kit Link Assy Left (with 2-8) 675K35434
99. Kit Link Assy Right (with 4, 6-8, 12, 13) 675K48081
To Next Page
