MORTIGUADOR TRASERO



REMOVING THE REAR SHOCK
1. Place the vehicle on a flat surface

WARNING
Securely support the vehicle so there is no risk
of falling.

NOTE:
Place the vehicle on a suitable stand so that
the rear wheel is elevated.


CHECKING THE REAR SHOCK
1.
Check:
•
Rear shock absorber rod. Deformation /
damage
Replace יו
the
rear shock.
•Rear shock.
Oil Leaks
Replace יו
the
rear shock.
•
Spring
Damage / wear
Replace יו
the
rear shock.
•
Hubs
Damage / wear
Replace יו
the
rear shock.
•
Screws
Curves / damage / wear
Replace יו.

Rear shock mounting

1. Assembly:
•Rear Shock

2. Tighten:
•Rear shock absorber upper nut

Rear shock absorber upper nut
40 Nm (4.0 m · kg, 29 ft · lb)


•
Rear shock lower nut

Rear shock lower nut
60 Nm (6.0 m · kg, 43 ft · lb)

3. Fit:
•
Rear shock. (Refer to "ADJUSTING THE
REAR SHOCK" on page 3-21)

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
