Yamaha FZ-16 2015 User Manual

7-38
COMPONENTES EL
É
CTRICOS







Starter cut relay
b. Turn the ignition switch to "ON".
c. Measure the input voltage signal relay
1
of rotation.

Output voltage relay turn signal 12 V
DC
2
3
LB RB
RW


1. Positive battery terminal
2. Negative battery terminal
3. Tester positive probe
4. Tester negative probe


Result
Continuity
(Between "1" and "3")

VERIFICATION OF RELAY TURN SIGNAL
1. Check:
• Input voltage relay turn signal
OOS
יו The from circuit
switch to the relay coupler turn signal is faulty
and must be repaired.

Input voltage relay turn signal DC 12 V

a. Connect the multimeter to the terminal relay
turn signal, as shown.

Multimeter



• Positive tester probe יו
coffee
"1"
• Negative tester probe יו
land
2. Check:

• The output voltage relay turn signal. OOS
Replace יו.

a. Connect the multimeter to the terminal relay turn
signal, as shown.

Multimeter



• Positive tester probe יו
brown / white "1"
• Negative tester probe יו
land





1

Br / W

Br




b. Turn the main switch to "ON".
c. Measuring the output voltage relay turn signal.






Br / W

Br
1

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
