4-55
CADENA DE
TRANSMISI
Ó
N




6.
Check:
•
Gear
Refer to "REAR WHEEL" on
page 4-12

ASSEMBLY DRIVE CHAIN
1.
Lubricate:
•
Drive chain

Recommended lubricant chain
lubricant suitable for O-ring
chains

2.
Assemble:
•
Drive chain
•
Drive sprocket
•
Retention of the drive sprocket

Screw retention of the drive sprocket
10 Nm (1.0 m · kg, 7.2 ft · lb)

3.
Assemble:
•
Rocker
Refer to "SWINGARM" on
page 4-49
•Rear Wheel
Refer to "REAR WHEEL" on
page 4-12

4.
Fit:
•
Chain slack transmission See "CLEARANCE
DRIVE CHAIN" on page
3-16

Clearance transmission
chain
30-40 mm

CAUTION
A string stretched excessively load the engine
and other vital parts and a loose chain can go out
and damage the swingarm or cause an accident.
Therefore, maintaining the tension of the
transmission chain within specification limits.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha FZ-16 2015 and is the answer not in the manual?

Yamaha FZ-16 2015 Specifications

General IconGeneral
Engine TypeAir-cooled, 4-stroke, SOHC, 2-valve
Displacement153 cc
Bore x Stroke58.0 mm x 57.9 mm
Compression Ratio9.5:1
Maximum Power14 PS @ 7500 rpm
Fuel SystemCarburetor
Transmission Type5-speed constant mesh
Front SuspensionTelescopic fork
Rear SuspensionMonocross
Front BrakeDisc
Rear BrakeDrum
Front Tire100/80-17
Rear Tire140/60-R17
Fuel Tank Capacity12 liters
Kerb Weight137 kg
Overall Length1, 975 mm
Overall Width770 mm
Overall Height1, 045 mm
Seat Height790 mm
Wheelbase1, 335 mm
Ground Clearance160 mm
Starting SystemElectric start
Lubrication SystemWet sump
Clutch TypeWet, multiple-disc
Frame TypeDiamond
Maximum Torque14 Nm @ 6000 rpm
Ignition SystemCDI
