Need help?Do you have a question about the Yamaha FZ-16 2015 and is the answer not in the manual?
General| Engine Type | Air-cooled, 4-stroke, SOHC, 2-valve |
|---|---|
| Displacement | 153 cc |
| Bore x Stroke | 58.0 mm x 57.9 mm |
| Compression Ratio | 9.5:1 |
| Maximum Power | 14 PS @ 7500 rpm |
| Fuel System | Carburetor |
| Transmission Type | 5-speed constant mesh |
| Front Suspension | Telescopic fork |
| Rear Suspension | Monocross |
| Front Brake | Disc |
| Rear Brake | Drum |
| Front Tire | 100/80-17 |
| Rear Tire | 140/60-R17 |
| Fuel Tank Capacity | 12 liters |
| Kerb Weight | 137 kg |
| Overall Length | 1, 975 mm |
| Overall Width | 770 mm |
| Overall Height | 1, 045 mm |
| Seat Height | 790 mm |
| Wheelbase | 1, 335 mm |
| Ground Clearance | 160 mm |
| Starting System | Electric start |
| Lubrication System | Wet sump |
| Clutch Type | Wet, multiple-disc |
| Frame Type | Diamond |
| Maximum Torque | 14 Nm @ 6000 rpm |
| Ignition System | CDI |
