Yamaha FZ-16 2015 User Manual

MOTOR
3-11




d. Tighten the locknut.
e. Slide the rubber cover to its original position.
NOTE:
If the free play specified clutch cable, can not be
obtained on the handlebar side, the adjusting nut
used in the motor side.



Motor side
a. Loosen the locknut "1"
b. Turn the adjustment screw "2" in direction "a"
or "b" to obtain the specified free play of the
clutch cable.
Direction "a"
The free play is increased clutch cable
Direction "b"
The free play is decreased clutch cable

NOTE:
Keep the right handlebar


1
1.
Remove:
Seat
Refer to "GENERAL CHASSIS" on page 4-1
2. Remove:
Cover the air filter box "1" air filter
element
1








1
to
b
2


3. Clean:
Air filter element "1"
Apply dry compressed air from the internal surface
of the outside of the air filter element.


c.
Tighten the locknut.

Locknut
9 Nm (0.9 m · kg, 6.5 ft · lb)



CLEANING THE AIR FILTER ELEMENT
NOTE:
There inspection hose "1" at the base of the air
filter housing. If there is dust and / or water
accumulated in the hose, clean the air filter
element and air filter box.
1

4. Check:
Air filter element
Replace damaged יו
5. Assembly:
Assembly:
Cover the air filter box (along with gaskets)

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
