SISTEMA ELECTRICO




4. Assembly:
•Lamp bulb
Secure the new lamp bulb holder with
bulb lamp
CAUTION:
Avoid touching the glass part of the bulb to keep
it free Cembran oil, otherwise the transparency
of glass, the bulb life and brightness will be
adversely affected. If the lamp bulb is dirty, wipe
it with a cloth moistened with alcohol or lacquer
thinner.

5. Assembly:
•Lamp bulb holder
6. Assembly:
•Cover lamp bulb
CHANGE OF LIGHT AUXILIARY
The following procedure applies to the low beam
bulb and high beam.
1.
Remove:
•Side Covers (see Changing the bulb of the
lamp) on page 3-22
•The connections of the indicator signal
turn (see Changing the bulb of the lamp)
on page 3-22
2.
Remove:
• auxiliary Bulb "1 as shown in
illustration ".

BEAM ADJUSTMENT OF FAROLA The
following procedure applies to adjust the light
beam of the streetlight.
Loosen the screw and move the lamppost
lamppost as follows to adjust the beam of the
lamp

Steering
The beam of light from the lamp low
Address b
The beam of light from the lamp rises

1







BULB REPLACEMENT REAR / BRAKE CYLINDER

1. Remove:
•Screw "1"
•Lens "2"



1

2t
o



2. Push the bulb "1" and gently rotate
counterclockwise.

1

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
