Yamaha FZ-16 2015 User Manual

5-8
CUL
A
T
A


whole.

2. Check:
•
Butt.
Damage / scratches → Replace.
•
Water jacket of the cylinder head
Mineral deposits oxide /
יו Delete.
3. Measure:


a. ¼ tooth
b.
Correct
1.
Contact roller chain
2.
Camshaft sprocket
•Deformation of the cylinder head.
OOS → Grind the butt.
2.
Check:
•
Guide chain
(Side Exhaust)
Damage / wear
Replace יו.
Strain Limit
0.03 mm


a. Put a rule "1" and a feeler gauge
"2" along the cylinder
head.

b. Measure the deformation.

INSPECTION OF TENSION DISTRIBUTION
CHAIN
1.
Check:
•
Tensor of the distribution chain. Cracks / damage /
movement
unequal
Replace יו.

a. Lightly press the tensioner rod chain inside
the box tensioner timing chain by hand.
NOTE:
While pressing the tensioner rod chain, turn to the
right with a
screwdriver "1" until it stops
c. If the limit is exceeded, the butt rectified as
follows.
d.
Place a wet sandpaper 400-600 on
the rectifying plate and the cylinder head
surface with a pattern of sanding a figure
eight.
NOTE:
To ensure a level surface, turn the head several
times.

INSPECTION CAMSHAFT SPROCKET AND
CHAIN GUIDE DISTRIBUTION

1. Check:
•
Camshaft sprocket
Over one quarter of wear "a" in the tooth
יו
Replace the camshaft sprocket, timing chain
and crankshaft as a
1






b. Remove the screwdriver and slowly release
the tensioner rod chain.
c. Make sure the tensioner rod chain leaves the
box of ten so r na ca dist ri bu if n ci ng probl
em as. If there is sudden movement
procedures, replace the tensioner chain.

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
