Yamaha FZ-16 2015 User Manual

2-12
ESPECIFICACIONES EL
É
CTRICAS



ELECTRICAL

Voltage
System voltage
12V

Ignition system
Ignition system DC, CDI
feed type
Digital
Ignition advance (B.T.D.C.)
7.0 ° / 1400r/min
Coil Resistance Pulse 192-288Ù
at 20 ° C

Ignition Coil
Primary coil resistance 0.32-0.48Ù
at 20 °
C secondary coil resistance 5.68-8.52Ù
at 20 °
C

Plug cap
Material
Resin
Resistance 5kÙ
at 20 ° C

Magneto CA
Standard Output 14.0V 125W @ 5000 rpm
Resistance of the stator winding 0464-0.696Ù
at 20 ° C


Regulator / rectifier
Regulator Type Semiconductor-Closed Circuit
Regulated voltage (CD) 13.7-14.7 V
rectifier capacity 20.0 A

Battery
Model
AB5L-B
voltage, capacity
12 V, 5.0 Ah
rate amperage 10 hours
5.0A

Lamp bulb
Bulb type Halogen bulb

Voltage, wattage bulb and quantity
Streetlight 12 V, 35 W X 1 W/35.0
Tail / Brake 12 V, 5.0 W X 1 W/21.0
Front directional light 12 V, 10.0 W × 2
Rear directional light 12 V, 10.0 W × 2
Light Meter
L.E.D.
Auxiliary light 12 V, 5.0 W × 1


Indicator Light
LED indicator light neutral indicator light LED
directional indicator light beam LED Warning Light
LED engine failure

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
