Yamaha FZ-16 2015 User Manual

EMBRAGUE
5-40



2.
Check:
•
Primary drive gear
Damage / wear
Replace יו gear
primary drive and clutch as a whole.
Excessive noise during operation
יו
Replace the primary drive gear and the clutch
as a whole.
3. Install:
•
Primary Drive Gear See "BALANCER
SPROCKET" on page 5-49.
PRIMARY DRIVEN GEAR INSPECTION
1. Check:
•
Primary driven gear "1"
Damage / wear
Replace יו gear
primary drive and clutch as a whole. Excessive
noise during
operation
Replace יו
drive gear
primary and the clutch as a whole.
NOTE:
Make sure the corners with sharp edges of the thrust
washer "a" is placed opposite the clutch disc
holders.



1
to



3.
Install:
•
Clutch disc carrier "1"
•
Lockwasher "2" New
•
Nut caddy
NOTE:
•Lubricate the threads of the nut and clutch disc
holder contact surfaces of the lock washer with
engine oil.
1
•
Align the notch "a" in the washer with a lower rib
"b" in the tray clutch.


New 2
1



CLUTCH ASSEMBLY
1. Install:
•Conical spring washer "1"
NOTE:
Install the conical washer, as shown in the
illustration.
b




to


4.
Tighten:
•
Caddy clutch nut "1"

1
Clutch Nut caddy
70 Nm (7.0 m · kg, 50 ft · lb)

NOTE:
While holding the tray clutch "2" with the clutch
holder "3", press the
caddy clutch nut.


2. Install:
•
Clutch Bell
Clutch Holder
YSST-733
•
Thrust washer "1"

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
