Yamaha FZ-16 2015 User Manual

2-21
PUNTOS DE LUBRICACI
Ó
NYTIPOS DE LUBRICANTE



LUBRICATION POINTS AND LUBRICANT TYPES


Point Lubrication
Lubricant
Edge oil seals
LS
Bearings
E
O-rings
LS
Head screws and washers
E
Thrust surface of the large end of the rod
E
Piston, piston rings and the inner surface of the cylinder
E
Inner surface of the balancer sprocket
E
Camshaft Lobe
M
Decompression cam
E
Valve stem seal
M
Valve stems (intake and exhaust)
M
The valve stem ends (intake and exhaust)
M
Rocker Shaft
E
Inner surface of the rocker shaft
M
Pin decompression lever
M
Oil Seal (Clutch cover)
E
Gear oil pump
E
Rotor oil pump (internal and external)
E
Pinion thrust surface free starter clutch
E
Freewheel shaft starter clutch
E
And internal surface of the pinion thrust surface clutch
Boot
E
Starter clutch rollers
E
Clutch thrust cam
E
Primary pinion inner surface
E
Clutch Pushrod (short and long) and pellet
E
Contact surface of the nut fixing the clutch hub and
lockwashe
r
E
Transmission gear (wheel and pinion) and necklace
M
Changes forks and fork guide bar changes
E
Gear drum
E
Axis of changes
E

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
