FUNCI
Ó
N DE AUT O-DIAGN
Ó
STICO
7-27





Symptom: The signals received from the speed sensor is not normal.

Component: Vehicle Speed Sensor

Order
Element / components and
probable cause
Check or maintenance job
Method
reintegration
1 Condition sensor assembly
speed.
• Check for loose or pressed.
Start the
engine and
activate
the speed
sensor,
pony endo
op
erating the
vehicle.
2 Connections
• Speed sensor coupler
• Cable Coupler main harness.
• Check that the coupler terminals
may have left.
• Check the lock status of the
couplers.
• If there is a malfunction, repair
and connect the coupler
3 Open wire or short circuit.
• Repair or replace if there is an
open or short circuit.
• Enter the speed sensor coupler and
coupler wiring harness.
4 Faulty speed sensor.
• Replace if defective
Refer to "CHECKING THE SPEED
SENSOR" on page 7 -
43.

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
