2-19
RES DE
PRIETE



TORQUE

Item
Size
the
thread
Amount
Torque

Observations
Screw steering column
M8
2
16 Nm (1.6 m kg, 12ft Ib)
E
Nut of the steering column
M22
1
110 Nm (11.0 m kg, 80ft Ib)
E
Lower ring nut (Initial)
M25
1
33 Nm (3.3 m.kg, 24ft.Ib)

Upper ring nut (Final)
M25
1
22 Nm (2.2 m.kg, 16ft.Ib)

Front fender
M6
1
6 Nm (0.6 m.kg, 4ft.Ib)

Switch / block
address
M6
2
7 Nm (0.7 m.kg, 5ft.Ib)

Support lamppost
M6
2
7 Nm (0.7 m.kg, 5ft.Ib)

Support lever
M6
2
7 Nm (0.7 m.kg, 5ft.Ib)

Screw handlebar switch
M5
2
10 Nm (1.0 m.kg, 7ft.Ib)

Screw meter and streetlight
M5
3
1 Nm (0.1 m.kg, 1ft.Ib)

License holder bolts
M5
2
4 Nm (0.4 m.kg, 3ft.Ib)

Screw lamppost
M6
3
7 Nm (0.7 m.kg, 5ft.Ib)

Screw end cap lamp
M4
4
2 Nm (0.2 m.kg, 1ft.Ib)

Front engine mount
M10
2
55 Nm (5.5 m.kg, 40ft.Ib)

Front Engine Support
M8
2
55 Nm (5.5 m.kg, 40ft.Ib)

Screw top engine mount
M8
3
30 Nm (3.0 m.kg, 22ft.Ib)

Swingarm pivot nut
M12
1
46 Nm (4.6 m.kg, 33ft.Ib)

Rear shock lower nut
M12
1
60 Nm (6.0 m.kg, 43ft.Ib)

Rear shock top nut
M12
1
40 Nm (4.0 m.kg, 29ft.Ib)

And tilt tension bar
M8
1
20 Nm (2.0 m.kg, 14ft.Ib)

Screw fuel cock
M6
2
7 Nm (0.7 m.kg, 5ft.Ib)

Ignition coil screw
M6
2
7 Nm (0.7 m.kg, 5ft.Ib)

Screw the cover later
M6
1
2 Nm (0.2 m.kg, 1ft.Ib)

Screw Battery Case
M6
3
7 Nm (0.7 m.kg, 5ft.Ib)

Screw gauge uni
fuel
M5
4
4 Nm (0.4 m.kg, 3ft.Ib)

Nut regulator, rectifier
M6
1
7 Nm (0.7 m.kg, 5ft.Ib)

Seat lock.
M6
1
4 Nm (0.4 m.kg, 3ft.Ib)

Screw end cap
M6
4
2 Nm (0.2 m.kg, 1ft.Ib)

Screw manigueta
M8
4
25 Nm (2.5 m.kg, 18ft.Ib)

Screw taillight
M5
2
2 Nm (0.2 m.kg, 1ft.Ib)

Nut reflective back
M5
1
2 Nm (0.2 m.kg, 1ft.Ib)

Screw ierta cub tank top
fuel
M5
10
2 Nm (0.2 m.kg, 1ft.Ib)

Tank side cover screw
fuel
M5
2
2 Nm (0.2 m.kg, 1ft.Ib)

Guide air half lead screw air
M5
2
2 Nm (0.2 m.kg, 1ft.Ib)

Screw air guide
M6
2
2 Nm (0.2 m.kg, 1ft.Ib)

Horn Nut
M6
1
7 Nm (0.7 m.kg, 5ft.Ib)

