Yamaha FZ-16 2015 User Manual

SISTEMA DE SEÑALIZACI
Ó
N
7-21



3.Verificar switch indicator light turn.
See the "Verifying SWITCHES" on
page 7-30.
Okt
4.Verificar
relay shift indicator
light. See "Verifying RELAY
TURN INDICATOR LAMP" on
page 7-38.
Okt

5.Verificar the signaling system
wiring. See section
"CIRCUIT DIAGRAM" on
page 7-17.
Okt
Replace the meter
㻚
NG




NG





NG

The horn switch is faulty. Replace the
switch left
Handlebar
㻚



Replace the relay turn indicator light.





Connect or repair wiring
㻚
signaling
system

The neutral indicator light does not light.

1.Check the light bulb and
socket neutral. Refer to the
section "Verifying the bulbs
and sockets bulbs" on page 7-
33.


NG




Replace light bulb in neutral, the socket or
both

Okt

2.Check neutral switch. See
"Verifying SWITCH" on page
7-30.


NG



Replace the neutral switch
㻚
Okt

3.Verificar the signaling
system wiring. See
section "CIRCUIT
DIAGRAM" on page 7-17.
Okt
Replace the meter
㻚
.

NG



Connect or repair wiring
㻚
signaling
system

The fuel gauge is not working.

1.Check fuel gauge. See "Checking
the fuel gauge" on page 7-43.
Okt


NG



Replace the fuel gauge
㻚
.

Yamaha FZ-16 2015 Specifications

General

Engine Type	Air-cooled, 4-stroke, SOHC, 2-valve
Displacement	153 cc
Bore x Stroke	58.0 mm x 57.9 mm
Compression Ratio	9.5:1
Maximum Power	14 PS @ 7500 rpm
Fuel System	Carburetor
Transmission Type	5-speed constant mesh
Front Suspension	Telescopic fork
Rear Suspension	Monocross
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-17
Rear Tire	140/60-R17
Fuel Tank Capacity	12 liters
Kerb Weight	137 kg
Overall Length	1, 975 mm
Overall Width	770 mm
Overall Height	1, 045 mm
Seat Height	790 mm
Wheelbase	1, 335 mm
Ground Clearance	160 mm
Starting System	Electric start
Lubrication System	Wet sump
Clutch Type	Wet, multiple-disc
Frame Type	Diamond
Maximum Torque	14 Nm @ 6000 rpm
Ignition System	CDI
