Yamaha Raptor 700R 2009 Service Manual

REAR SHOCK ABSORBER ASSEMBLY
4-55
EAS1S3L019
REAR SHOCK ABSORBER ASSEMBLY
Removing the rear shock absorber assembly
Order Job/Parts to remove Q’ty Remarks
Rear wheels Refer to “REAR WHEELS” on page 4-9.
1 Self-locking nut/bolt/spacer 1/1/1
2 Self-locking nut/bolt/spacer 1/1/1
3 Self-locking nut/bolt 1/1
4 Self-locking nut/bolt 1/1
5 Rear shock absorber assembly 1
6 Spacer/oil seal/bearing 1/2/1
7 Spacer/oil seal/bearing 1/2/1
8 Self-locking nut/bolt 1/1
9 Relay arm 1
10 Spacer/oil seal/bushing 1/2/2
11 Connecting arm 1
12 Dust cover 4
13 Spacer 1
14 Spacer 1
LS
LS
LS
LS
New
LS
LS
LS
New
LS
LS
2
2
2
1
1
1
6
3
6
LS
7
5
3
12
12
12
8
9
7
4
4
10
10
8
12
11
13
15
15
15
14
15
New
New
New
New
T
R
.
.
55 Nm (5.5 m
•
kg, 40 ft
•
Ib)
T
R
.
.
55 Nm (5.5 m
•
kg, 40 ft
•
Ib)
T
R
.
.
43 Nm (4.3 m
•
kg, 31 ft
•
Ib)
T
R
.
.
43 Nm (4.3 m
•
kg, 31 ft
•
Ib)
