LUBRICATION POINTS AND LUBRICANT TYPES
2-22
EAS20360
LUBRICATION POINTS AND LUBRICANT TYPES
EAS20370
ENGINE
Lubrication point Lubricant
Oil seal lips
O-rings
Bearings
Crankshaft pins
Timing chain sprocket inner surface
Connecting rod big end thrust surface
Piston pin
Piston surface
Valve stems, valve guides, and valve stem seals (intake and exhaust)
Valve stem ends (intake and exhaust)
Rocker arm shaft
Camshaft lobes
Decompressor lever pin
Decompressor lever spring
Water pump impeller shaft
Oil pump rotors (inner rotor 2 and outer rotor 2) and pump
Oil pump rotors (inner rotor 1 and outer rotor 1) and pump
Torque limiter
Starter idle gear and starter wheel gear inner surface
Primary driven gear
Clutch pull rod
Transmission gears (wheel and pinion)
Shift drum
Shift forks
Shift fork guide bar
Shift lever assembly
Shift shaft
Reverse shift shaft
Crankcase mating surface
Yamaha bond No.
1215 (Three bond
No.1215®)
AC magneto lead grommet (AC magneto cover)
Yamaha bond No.
1215 (Three bond
No.1215®)
LS
LS
E
E
M
E
E
E
M
M
E
M
E
E
E
E
LS
E
E
E
LS
M
E
E
M
E
E
E
