THERMOSTAT
6-3
EAS26440
THERMOSTAT
Removing the thermostat
Order Job/Parts to remove Q’ty Remarks
Front fender
Refer to “GENERAL CHASSIS” on page
4-1.
Coolant Drain.
1 Radiator inlet hose 1
2 Thermostat cover 1
3O-ring 1
4 Thermostat 1
5 Coolant temperature sensor 1
6 Copper washer 1
For installation, reverse the removal proce-
dure.
LS
5
6
2
3
4
1
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
New
New
New
