TIGHTENING TORQUES
2-19
EAS20350
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Engine upper bracket bolt M8 2 33 Nm (3.3 m·kg, 24 ft·lb)
Engine mounting nut (upper) M10 1 40 Nm (4 m·kg, 29 ft·lb)
Engine lower bracket bolt M8 4 41 Nm (4.1 m·kg, 30 ft·lb)
Engine mounting nut (middle) M10 1 66 Nm (6.6 m·kg, 48 ft·lb)
Engine mounting nut (lower) M10 1 66 Nm (6.6 m·kg, 48 ft·lb)
Swingarm pivot shaft nut M16 1 100 Nm (10 m·kg, 72 ft·lb)
Rear frame mounting bolt M10 4 54 Nm (5.4 m·kg, 39 ft·lb)
Oil tank bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Coolant reservoir bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear shock absorber assembly
nut (upper)
M12 1 55 Nm (5.5 m·kg, 40 ft·lb)
Relay arm nut (upper) M10 1 43 Nm (4.3 m·kg, 31 ft·lb)
Connecting arm nut M12 1 55 Nm (5.5 m·kg, 40 ft·lb)
Rear shock absorber assembly
nut (lower)
M10 1 43 Nm (4.3 m·kg, 31 ft·lb)
Relay arm nut (lower) M10 1 43 Nm (4.3 m·kg, 31 ft·lb)
Rear axle pinch bolt M8 4 21 Nm (2.1 m·kg, 15 ft·lb)
Rear axle guide bolt M12 1 55 Nm (5.5 m·kg, 40 ft·lb)
Swingarm skid plate bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive chain guide bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive sprocket cover bolt M6 2 10 Nm (1 m·kg, 7.2 ft·lb)
Upper front arm nut M10 2 38 Nm (3.8 m·kg, 27 ft·lb)
Lower front arm nut M10 4 55 Nm (5.5 m·kg, 40 ft·lb)
Front shock absorber assembly
nut (upper)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Front shock absorber assembly
nut (lower)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Pitman arm nut M14 1 180 Nm (18 m·kg, 130 ft·lb)
Steering stem bushing nut M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Use a
lock
washer.
Handlebar holder bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Tie-rod end locknut M12 18 Nm (1.8 m·kg, 13 ft·lb)
Front axle nut M14 2 70 Nm (7 m·kg, 50 ft·lb)
Steering knuckle and front upper
arm nut
M10 4 25 Nm (2.5 m·kg, 18 ft·lb)
Steering knuckle and front lower
arm nut
M10 4 25 Nm (2.5 m·kg, 18 ft·lb)
Steering knuckle and tie-rod ball
joint nut
M10 2 25 Nm (2.5 m·kg, 18 ft·lb)
