Yamaha Raptor 700R 2009 Service Manual

AC MAGNETO AND STARTER CLUTCH
5-31
EAS1S3L026
AC MAGNETO AND STARTER CLUTCH
Removing the AC magneto and starter clutch
Order Job/Parts to remove Q’ty Remarks
Engine oil
Drain.
Refer to “CHANGING THE ENGINE OIL” on
page 3-12.
Front fender
Refer to “GENERAL CHASSIS” on page
4-1.
Oil tank inlet hose Refer to “ENGINE REMOVAL” on page 5-1.
Drive sprocket cover Refer to “CHAIN DRIVE” on page 4-63.
1 AC magneto coupler 1 Disconnect.
2 Crankshaft position sensor coupler 1 Disconnect.
3 AC magneto cover 1
4 AC magneto cover gasket 1
5 Dowel pin 2
6 Lead holder 1
7 Crankshaft position sensor 1
8 Stator coil 1
9 Torque limiter 1
10 Starter idle gear 1
LT
LT
E
LS
New
LT
E
E
E
New
LT
LT
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
5
8
3
4
(14)
(3)
15
5
16
11
9
14
10
13
12
7
6
1
2
T
R
.
.
60 Nm (6.0 m
•
kg, 43 ft
•
Ib)
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
