6.5.5 Settings
Table 51: SDEPSDE Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
OpMode 3I0Cosfi
3I03U0Cosfi
3I0 and fi
-
- 3I0Cosfi Selection of operation mode for protection
DirMode Forward
Reverse
- - Forward Direction of operation forward or reverse
RCADir -179 - 180 Deg 1 -90 Relay characteristic angle RCA
RCAComp -10.0 - 10.0 Deg 0.1 0.0 Relay characteristic angle compensation
ROADir 0 - 90 Deg 1 90 Relay open angle ROA used as release in
phase mode
INCosPhi> 0.25 - 200.00 %IB 0.01 1.00 Set level for 3I0cosPhi, directional
residual overcurrent, in % of IBase
SN> 0.25 - 200.00 %SB 0.01 10.00 Set level for 3I0U0cosPhi, starting inverse
time count, in % of SBase
INDir> 0.25 - 200.00 %IB 0.01 5.00 Set level for directional residual
overcurrent protection, in % of IBase
tDef 0.000 - 60.000 s 0.001 0.100 Definite time delay directional residual
overcurrent
SRef 0.03 - 200.00 %SB 0.01 10.00 Reference value of residual power for
inverse time count, in % of SBase
kSN 0.00 - 2.00 - 0.01 0.10 Time multiplier setting for directional
residual power mode
OpINNonDir> Off
On
- - Off Operation of non-directional residual
overcurrent protection
INNonDir> 1.00 - 400.00 %IB 0.01 10.00 Set level for non-directional residual
overcurrent, in % of IBase
tINNonDir 0.000 - 60.000 s 0.001 1.000 Time delay for non-directional residual
overcurrent
TimeChar ANSI Ext. inv.
ANSI Very inv.
ANSI Norm. inv.
ANSI Mod. inv.
ANSI Def. Time
L.T.E. inv.
L.T.V. inv.
L.T. inv.
IEC Norm. inv.
IEC Very inv.
IEC inv.
IEC Ext. inv.
IEC S.T. inv.
IEC L.T. inv.
IEC Def. Time
Reserved
RI type
RD type
- - IEC Norm. inv. Operation curve selection for IDMT
operation
tMin 0.000 - 60.000 s 0.001 0.040 Minimum operate time for IEC IDMT
curves
Table continues on next page
Section 6 1MRK 511 287-UEN A
Current protection
112
Technical manual
